    Heavy Duty Framed Glass Sliding Door with Sensors/Quality Commercial Automatic Sliding Door DE550

    Ask Lasest Price
    Brand Name : Elegint
    Model Number : DE550
    Certification : CE
    Price : Negotiatable
    Payment Terms : Western Union, T/T, L/C
    Supply Ability : 3000 sets/ month
    Delivery Time : 5 workding days
    • Product Details
    • Company Profile

    Heavy Duty Framed Glass Sliding Door with Sensors/Quality Commercial Automatic Sliding Door DE550

    Characteristics and Advantages


    (1) Durability: Over 10 years long life span;


    (2)Anti-Derailment:Newly designed hanger device to proof door leaf get out of aluminium track;


    (3)Resistance to Deformation: Bearing structure is tough enough to resist deformation;


    (4)Safety:Operated by receiving signals from sensors, the door moves automatically and it will reverse back once there is any objects between the door leaves and with safety sensor installed at both sides to enhance the safety;


    (5)Real-Time Memory function;


    (6)Fire Emergency Safety Function;


    (7)Full open or half open can be controlled according to different situations;


    It can be used both for framed door bodies or frameless glass doors; are available in either single sliding, bi-parting or telescopic configurations;


    Technical Specification

    ParameterDE-550
    Range of the DoorSingle-leafDouble-leaf
    Door Leaf max Weight200kgx1200kg x 2
    Door Width900-2800mm900-2800mm
    Installation TypeSurface Mounting
    Height of Aluminium Track125mm
    Width of Aluminium Track156mm
    Power SupplyAC100V-15% -- AC240V+10%
    Boost VoltageDC 24V, 640mA
    Eletric Fuse6.3A
    Opening Speed(Single leaf)700mm/s (adjustable)
    Closing Speed(Single leaf)700mm/s (adjustable)
    Opening Delay Time0-60s (adjustable)
    Power Consumption250W
    Ambient Temperature-20+50 ℃

    Control Functions:


    1.16 bit microcomputer control system, only need to learn one time after installation;


    2.Operation Options: Close, Automatic, Open, Half Open, Single Pass, Reset;


    3.Reverse back once it senses obstacles;


    4.Portable for electromechanical lock;


    5.Portable for safety sensor;


    6.With 24V output;


    7.Portable for fire alarm or building system signal and also portable for UPS backup battery;
